Diode Laser · Professional Hair Reduction
Portable Diode Laser Hair Removal (QM-110D)
Model: QM-110D
QM-110D diode laser hair-removal system QM-110D is a professional diode-laser platform designed for clinics, medical spas, beauty salons and skin-care centers. Its standard 808nm configuration can be combined with 940nm and 1064nm wavelengths, with 755nm available as an option. Final wavelength, handpiece power and spot-size configuration are confirmed in the quotation.
Read the full overviewPricing
Available upon inquiry
Competitive factory-direct pricing
Why order from ZENLASE?
- Written quotation
- Certificate copies sent before you order
- Consumables & spare parts supplied long-term
- Operator training materials in the languages agreed for your order
- One contact from quote to after-sales
Product Overview
QM-110D diode laser hair-removal system
QM-110D is a professional diode-laser platform designed for clinics, medical spas, beauty salons and skin-care centers. Its standard 808nm configuration can be combined with 940nm and 1064nm wavelengths, with 755nm available as an option. Final wavelength, handpiece power and spot-size configuration are confirmed in the quotation.
Working principle
The system applies selective photothermolysis: laser energy is absorbed by melanin in the hair shaft and follicle and converted into heat. The treatment objective is to heat the follicular structure while the sapphire contact tip cools the epidermis. Treatment parameters must be selected by a trained operator for the client’s skin type, hair characteristics and treatment area.
Key configuration advantages
- Multi-wavelength options: configurations cover 755nm, 808nm, 940nm and 1064nm according to the selected handpiece.
- Adjustable handpiece power: 600W to 1600W options support different clinic workloads.
- Multiple spot sizes: 12×12mm, 12×24mm and 12×36mm, with a φ6mm precision tip available as an option.
- Contact cooling: water circulation, condenser air cooling, TEC and a sapphire contact surface work together to manage skin-surface temperature.
- Operator interface: a 15.6-inch main touchscreen displays treatment parameters; handpiece screen availability depends on the selected configuration.
- 1–10Hz repetition rate: supports treatment of small and large areas with settings adjusted to the treatment plan.
Suitable users and applications
The system is intended for professional hair-reduction services in beauty salons, hospitals, skin-care centers and spas. Availability, permitted claims and operator requirements vary by destination country. Request the exact configuration, manual and model-specific documents before ordering.
Photos and specifications on this page describe available QM-110D configurations. The Proforma Invoice and confirmed configuration sheet take precedence for the delivered unit.
Applications
Common applications for this model. Final protocols and suitability are confirmed for the selected configuration.
Technology
How this technology worksMulti-wavelength configurations: 755nm / 808nm / 940nm / 1064nm
600–1600W adjustable handpiece options
12×12mm, 12×24mm, 12×36mm and optional φ6mm spot sizes
Water, air, TEC and sapphire contact cooling
15.6-inch main touchscreen
1–10Hz adjustable repetition rate
Wavelength
808nm standard +
Power
1500W
Spot Size
12×12mm,
Cooling
Water circulation +
QM-110D
Technical Specifications
- 01Cooling System
- Water circulation + condenser air cooling + TEC sapphire contact cooling
- 02Electrical Requirements
- 90–130V, 50/60Hz or 200–260V, 50Hz
- 03Frequency
- 1–10Hz
- 04Laser Power Supply
- 1500W
- 05Laser Stacks Power
- 600–1600W (adjustable)
- 06Laser Type
- Diode Laser
- 07Machine Dimensions
- 67 × 51 × 61.5cm
- 08Net Weight
- 45kg
- 09Operation Language
- English; interface language can be customized subject to confirmation
- 10Pulse Duration
- 10–400ms
Make this system fit your brand
Logo, boot screen, interface language, manuals and packaging can be evaluated for this model. Available items, MOQ and lead time are confirmed in the quotation.
- Machine logo or nameplate
- Boot screen and interface theme
- Interface and manual language
- Labels, manuals and packaging
Warranty & After-Sales, in Concrete Terms
The exact terms are printed on your Proforma Invoice before payment — no verbal promises.
Model-Specific Warranty
Duration, covered components and exclusions are confirmed in writing before payment.
Remote Engineer Support
Technical questions are coordinated by video call with factory engineers when needed.
Parts Plan Confirmed
Availability, price and dispatch method are confirmed for the selected model.
Operator Training Materials
Start-up guidance, manuals and available video materials are confirmed for the selected model.
How Ordering Works
See the full process- 1
Inquiry
Sales & technical coordination
- 2
Quote & PI
Written quotation
- 3
Deposit
Terms in PI
- 4
Production & QC
Test video sent
- 5
Ship & Support
Documents + training
Frequently Asked Questions
Which wavelengths are available?
The standard configuration centers on 808nm. 940nm and 1064nm can be combined, while 755nm is optional. Confirm the exact handpiece before ordering.
What spot sizes can be supplied?
The listed options are 12×12mm, 12×24mm and 12×36mm, with a φ6mm precision tip available as an option.
How does the cooling system work?
It combines water circulation, condenser air cooling, TEC cooling and a sapphire contact surface. Operating temperature and cooling level must be set according to the manual and treatment plan.
Can the interface language be customized?
English is standard. Other interface languages may be available and must be confirmed for the selected production configuration.
What documents are available?
Tell us the destination country and exact configuration. We will provide the model-specific manual, packing information and applicable certificate copies available for verification before payment.
