Diode Laser · Hair Removal

Diode Laser Hair Removal System

Model: QM-808A+ NEW

established technology Technology for long-term hair reduction The QM-808A+ is a professional diode laser system that combines three established in professional aesthetic use wavelengths – 755nm, 808nm, and 1064nm – in a single device.

Read the full overview

Written Warranty Terms

Global Shipping

Remote Support

Pricing

Available upon inquiry

Competitive factory-direct pricing

Request Quote & Specs WhatsApp Us Now Request Brochure

Model-specific quote · No obligation

Why order from ZENLASE?

Written quotation
Certificate copies sent before you order
Consumables & spare parts supplied long-term
Operator training materials in the languages agreed for your order
One contact from quote to after-sales

Product Overview

established technology Technology for long-term hair reduction

The QM-808A+ is a professional diode laser system that combines three established in professional aesthetic use wavelengths –755nm, 808nm, and 1064nm– in a single device. Designed for clinics, medical spas, and beauty centers, it is designed for professional hair-reduction treatments across a range of skin types with settings selected by a trained operator (Fitzpatrick I–VI). With high average power (up to 1600W), large spot sizes, and an advanced contact cooling system, it is designed to support treatment comfort; client response and possible side effects vary.

Key Features

Triple Wavelength Technology

755nm (Alexandrite):Ideal for light-colored and thin hair; targets the hair bulge superficially.
808nm (Classic Diode):The established technology – deep penetration, fast treatment, configurable for darker skin.
1064nm (Nd:YAG):a suitable option for dark skin (Types V–VI); deepest penetration for coarse hair.

Powerful Performance

Energy density: up to 120 J/cm²
Frequency: 1–10 Hz
Pulse width: 10–400 ms
Continuous 24-hour operation

Large Spot Sizes– 13×16mm, 13×22mm, 13×30mm, plus a nose hair tip. Covers large areas quickly.

Advanced Contact Cooling– Sapphire tip cools down to -10°C, protecting epidermis and supporting designed for improved treatment comfort treatments.

User-Friendly Interface– 12-inch true-color touchscreen with intuitive menus: mode selection, gender selection, skin type & treatment area selection, and real-time parameter display.

Interchangeable Handpieces– Easy to swap tips for different body areas.

Technical Specifications

Parameter	Specification
Technology	Diode Laser Hair Removal
Handle Power	500W / 600W / 800W / 1000W / 1200W / 1600W (optional)
Wavelength	808nm / 755nm+808nm+1064nm
Energy Density	1–120 J/cm²
Frequency	1–10 Hz
Spot Sizes	13×16mm, 13×22mm, 13×30mm, Nose hair tip
Laser Bars	10 / 12 / 16 bars
Pulse Width	10–400 ms
Display	12-inch True Color Touch Screen
Cooling Levels	1–5 (temperature range: -10°C to 5°C)
Cooling System	Semiconductor + Water Circulation + Air Radiator with Condenser
Working Time	Continuous 24 hours
Voltage	220V ±10%, 10A 50Hz / 110V ±10% (optional)

Treatment Protocol Summary

Pre-Treatment

No sun tanning for 3–4 weeks.
No waxing/tweezing for 2–3 weeks – shave only.
Shave the area the night before or morning of treatment.
Remove makeup and clean the area.
Optional: topical anesthetic 60 minutes before.

During Treatment

Start with lower energy and increase gradually.
Overlap pulses by 1/3 for complete coverage.
Keep the handpiece in contact with skin.
Always wear protective eyewear.

Post-Treatment

Keep area clean and dry; gently wash twice daily.
Apply cooling compresses if needed.
Avoid makeup for 4–5 days.
No sun exposure for 1 month; use high-SPF sunscreen.
No scrubbing or exfoliating for 7 days.

Treatment Course– 3–5 sessions, 4–6 weeks apart.

Safety & Contraindications

Contraindications

Pregnancy
Photosensitive medication use
Recently tanned skin (within 1 month)
History of keloid scarring
Diabetes (unless controlled)
Cancer (especially skin cancer)
Heart disease, epilepsy

Safety Features

Emergency button for instant power-off
Leakage protection
Water circulation alarm system
Automatic temperature monitoring

Common Side Effects (Temporary)

Mild pain during treatment
Redness/edema (subsides in 3–7 days)
Minor risk of temporary pigmentation changes
Possible scabs or blisters (heal in 5–10 days)
Temporary skin fragility

FAQ

Q: What skin types can this treat?
A: a range of skin types with settings selected by a trained operator (I–VI). Use 755nm for light skin, 808nm for medium, and 1064nm for dark skin.

Q: Is the treatment painful?
A: The sapphire contact cooling (down to -10°C) significantly reduces discomfort. Most patients describe only a mild snapping sensation.

Q: How many sessions are needed?
A: 3–5 sessions, spaced 4–6 weeks apart, to target all hair growth cycles.

Q: How long does each session take?
A: Upper lip – ~2 minutes; Underarms – ~5 minutes; Lower legs – ~30 minutes.

Q: Can it treat light/blonde hair?
A: The 755nm wavelength is specifically effective for lighter and thinner hair.

Q: What cooling system does it use?
A: Three-stage cooling: semiconductor + water circulation + air radiator with condenser. Ensures stable operation and patient comfort.

Configuration notice: Specifications, accessories, interface options and permitted uses vary by destination market and confirmed configuration. The Proforma Invoice, configuration sheet and model-specific documents supplied before payment take precedence.

Applications

Common applications for this model. Final protocols and suitability are confirmed for the selected configuration.

Hair Removal

Technology

How this technology works

Technology: Diode Laser Hair Removal

Handle Power: 500W / 600W / 800W / 1000W / 1200W / 1600W (optional)

Wavelength: 808nm / 755nm+808nm+1064nm

Frequency: 1–10 Hz

Spot Sizes: 13×16mm, 13×22mm, 13×30mm, Nose hair tip

Display: 12-inch True Color Touch Screen

Wavelength

808nm / 755nm+808nm+1064nm

Power

500W / 600W / 800W / 1000W / 1200W / 1600W (optional)

Spot Size

13×16mm, 13×22mm, 13×30mm, Nose hair tip

Cooling

1–5 (temperature range: -10°C to 5°C)

Private Label

Make this system fit your brand

Logo, boot screen, interface language, manuals and packaging can be evaluated for this model. Available items, MOQ and lead time are confirmed in the quotation.
